DF3A-4P-2DSA
Manufacturer:
Hirose Electric
Mfr.Part #:
DF3A-4P-2DSA
Datasheet:
Description:
Headers and Wire Housings Through Hole Header Number of Positions:4 Pitch:2 mm
| Parameter | Value |
|---|---|
| Termination | Press-Fit, Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Bulk |
| RoHS | Compliant |
| Insulation Resistance | 1 GΩ |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass |
| Pitch | 2 mm |
| Gender | Pin (Male) |
| Number of Contacts | 4 |
| Mounting Style | Through Hole, Vertical |
| lead free status | Lead Free |
| operating temperature | 85.0 °C |
| rohs status | Compliant |
| reach svhc compliance | No SVHC |
| Connector Type | Header |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Insulation Material | Nylon |
| Housing Material | Plastic |
| Contact Resistance | 30 mΩ |
| size width | 5.00 mm |
| size length | 10.0 mm |
| size height | 5.00 mm |
| voltage rating ac | 30 V |
| Housing Color | Black |
| pin pitch | 2.00 mm |
| Mating Post Length | 3.1 mm |
| Termination Post Length | 2.9 mm |
Stock: 4758
Distributors
pcbx
pcbxUnit Price$0.14363
Ext.Price$0.14363
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.14363 | $0.14363 |
| 10 | $0.11969 | $1.19690 |
| 50 | $0.11035 | $5.51750 |
| 100 | $0.10174 | $10.17400 |
| 500 | $0.09419 | $47.09500 |
| 1000 | $0.08720 | $87.20000 |
